Integrated heat exchanger
HTX
Maximum flexibility between comfort and ease of installation
The HTX integrated heat exchanger series offers high-performance heating solutions ranging from 3.3 kW to 6.6 kW, versatile installation options and durable components, ensuring a comfortable and reliable experience in any vehicle.
Model HTX S
Model HTX S HD
Model HTX M
Model HTX M HD
- HTX S
- HTX S HD
- HTX M
- HTX M HD
Benefits of the HTX heat exchanger series
The HTX heat exchanger series delivers powerful heating (3.3 kW to 6.6 kW), flexible installation and robust components for a reliable and comfortable in-vehicle experience.
Product details
Product specification
The HTX series encompasses a variety of models, available in 12 V and 24 V, offering heating solutions from 3.3 kW to 6.6 kW. Each model is crafted for easy integration and optimal performance in recreational and special vehicles as well as marine applications.
Model overview
Select from the HTX S, HTX S HD, HTX M and HTX M HD models, available in both 12 V and 24 V, to find the ideal heating solution for your specific vehicle type and needs.
What is included
Each HTX heat exchanger is accompanied by a comprehensive accessory and installation kit, including control units, air vents, and ducts, ensuring a smooth integration and optimal functionality in any vehicle.
Downloads
| Model overview | Thermo Top Eveo 4 | Thermo Top Evo 5 | Thermo Top Evo 5+* | |||
|---|---|---|---|---|---|---|
| Diesel | Gasoline | Diesel | Gasoline | Diesel | Gasoline | |
| ECE approval number ECE R12 (heating) | E1 00 0258 | E1 00 0258 | E1 00 0258 | |||
ECE approval number ECE R10 | E1 04 5627 | E1 04 5627 | E1 04 5627 | |||
| Heating capacity, part load/ full load (kW) | 2.5/4.0 | 2.8/4.0 | 2.5/5.0 | 2.8/5.0 | 2.5/5.0 | 2.8/5.0 |
| Fuel consumption, part load / full load (l/h) +/- 10% | 0.31/0.49 | 0.39/0.56 | 0.31/0.62 | 0.39/0.70 | 0.31/0.62 | 0.39/0.70 |
| Nominal voltage | 12 | 12 | 12 | |||
| Rated power consumion without coolant pump, part load/ful l load (W) without vehicle’s fan, +/- 10% | 12/21 | 15/21 | 12/33 | 15/33 | 12/33 | 15/33 |
| Fuels | Diesel DIN EN 590,Paraffinic fuel (HVO / GTL)DIN EN 15940 | E0-E10 EN 228, E85 DIN 51625 | Diesel DIN EN 590,Paraffinic fuel (HVO / GTL)DIN EN 15940 | E0-E10 EN 228, E85 DIN 51625 | Diesel DIN EN 590,Paraffinic fuel (HVO / GTL)DIN EN 15940 | E0-E10 EN 228, E85 DIN 51625 |
| Operating temperature range (°C) | -40 to +60 | |||||
| Dimensions L x W x H (mm) | 218 x 91 x 147 | 218 x 91 x 147 | 218 x 91 x 147 | |||
| Weight (kg) | 2.1 | 2.1 | 2.1 | |||
| Coolant pump U4847 Econ | - | |||||
| Volume flow against 0.14 bar (l/h) | 500 | |||||
| Dimensions L x W x H (mm) | 109x49x79 | |||||
| Weight (kg) | 0.3 | |||||
* More details can be found here
Integrated heat exchanger HTX - Datasheet
Download the integrated heat exchanger HTX datasheet.
- Size
- 399 KB
- Format
- application/pdf
