BlueCool V-Series
Air-conditioning system with variable speed control
The devices in the Webasto BlueCool V-Series are highly efficient air-conditioning systems with a chiller. Inverter-driven BLDC compressors with variable speed control reduce start-up current peaks. They are ideal for boats and yachts with three or more independent cabins. A central cooling system brings cool air into the cabins via a cooling water circuit and various air outlets. The units automatically adapt to environments with 50 or 60 Hz and to tropical seawater environments. They are operated via the central MyTouch display from Webasto.
V64 T and V77 T
V64 T and V77 T
- V64 T and V77 T left
- V64 T and V77 T right
Benefits of BlueCool V-Series
Product details
Product specifications
- Cooling capacity: 8,500 - 77,000 BTU/h (2.5 - 22.6 kW)
- Heating function possible
- Nominal voltage: 230/240 V
- Frequency: 50/60 Hz
- Dimensions
- of the unit L x D x H in mm (type V50 M / type V64 T / type V77 T):
567 x 340 x 510 / 760 x 560 x 510 / 760 x 560 x 510 - of the unit incl. silent block L x D x H in mm (type V50 M / type V64 T / type V77 T):
590 x 378 x 548 / 760 x 560 x 550 / 760 x 560 x 550 - Dimensions of the electronics box L x D x H in mm (type V50 M / type V64 T / type V77 T):
560 x 190 x 465 / 560 x 190 x 465 / 560 x 190 x 465 - Dimensions of the chiller L x D x H in mm (type V50 M / type V64 T / type V77 T):
607 x 530 x 510 / 760 x 750 x 510 / 760 x 750 x 510 - Dimensions of the unit incl. silent block and box L x D x H in mm (type V50 M / type V64 T / type V77 T): 620 x 570 x 548 / 760 x 750 x 550 / 760 x 750 x 550
- of the unit L x D x H in mm (type V50 M / type V64 T / type V77 T):
- Weight
- of the core unit in kg (type V50 M / type V64 T / type V77 T): 47 / 90 / 90
- Weight of the electronics box in kg (type V50 M / type V64 T / type V77 T): 15 / 15 / 15
Model overview
- V50 M
- V64 T
- V77 T
