Power Test System
I-TS-3870
Single-channel system for testing and simulation
The I-TS system is a single-channel powerhouse for testing batteries, fuel cells, and powertrains (up to 1200 V and 1200 A), scaling to 1.3 MW in parallel. It tackles battery testing, simulation, and fuel cell loading, while also evaluating contactors, fuses, DC motors, charging columns, and even powering trains for maintenance.
Prioritizing safety (PLd) with features like emergency stops and isolated outputs, the I-TS offers versatile control (Modbus TCP/IP, CAN-Bus, SCPI) with optional Profibus, Profinet, and LabView compatibility. It boasts exceptional power with short-circuit protection, precise control, and fast current rise times, all user-friendly via a clear TFT display with touch operation. Expand functionality with optional features like insulation monitoring, parallel operation, discharge unit, water cooling, and an "overload" variant for short-term high-load testing. Contact us for specific overload inquiries.
Benefits of Power Test System I-TS-3870
Single-channel system for testing and simulation of batteries, fuel cells and powertrains. One output with up to 1200 V and 1200 A. Maximum power in single operation 650 kW, up to 1.3 MW in parallel operation.
Product details
Product specifications
The Type I-TS-3870 operates with an AC mains voltage of 380 / 400 / 440 / 480 / 690 V ± 10 %, 3-phase, PE, and a frequency of 50 / 60 Hz ± 5 %.]
Measurement accuracy: Voltage: 16-Bit ADC, Current: 16-Bit ADC
Control accuracy: Voltage: 0.1 % fs, Current: 0.1 % fs
Residual ripple: Voltage ≤ 0.1 % eff. fs, Current ≤ 0.1 % eff. fs
Voltage tolerance (dynamic 0-100 % INom in 3 ms): Battery tester: < 3% fs, Battery emulator: < 1% fs
Short circuit performance: Short circuit proof; systems up to 600 A: Icw: 3 kA, systems with 1000 A: Icw: 8 kA, systems with 1200 A: Icw: 15 kA
Permissible environmental conditions: Storage as per EN 60721-3-1, Transport as per EN 60721-3-2, Operation as per EN 60721-3-3
Environmental conditions: 1K21 / 1M11, +5 to +40 °C; 2K12 / 2M4, -45 to +70 °C; 3K22 / 3M11, +5 to +40 °C
Cooling method: Enforced air cooling (IP20, IP21, IP23) and enforced water cooling (IP54)
Safety of machinery - Safety-related parts of control systems: EN ISO 13849-1, EN ISO 13849-2
Safety of machinery: EN 60204-1 Exception: Sec. 11.3 Protection type see Technical Data, Sec. 13.2 Identification of conductors
EMC Standards: EN 61000-2-4 Class 3, EN 61000-6-2, EN 61000-6-4 / EN 55011 (Tab. 2), EN 61800-3 Cat.C2 (A1)
