BlueCool V-PRO Series

Efficient, high-capacity, marine cooling with the flexible BlueCool V-Pro Series chiller system

The Webasto BlueCool V-Pro Series is a variable speed chiller system designed to meet the cooling demands of mid-sized to super yachts and commercial boats. Offering modular units in 60, 90, 130, and 180 kBTU/h capacities, the BlueCool V-Pro system can be configured to deliver up to 1 million BTU/h of cooling power. With titanium condensers for outstanding corrosion resistance, the BlueCool V-Pro Series ensures long-lasting, efficient performance. Its advanced control system and autonomous modules make setup simple, providing flexible, powerful climate control for vessels of any size.

Discover the advantages of the BlueCool V-Pro Series

The Webasto BlueCool V-Pro Series offers a powerful and adaptable solution for boats that require a central chilled water system. Whether you're outfitting a mid-sized yacht or a commercial vessel, the BlueCool V-Pro Series’ modular design can combine up to six units, providing up to 1,080,000 BTU/h of cooling capacity. Each unit operates autonomously, with built-in control electronics and an intuitive color touchscreen interface for easy management. The BlueCool V-Pro Series also features titanium condensers for superior corrosion resistance, ensuring that the system performs reliably, even in the harshest marine environments. With a heat-pump function and a wide range of accessories, including manifold and rack systems, the BlueCool V-Pro Series provides unmatched flexibility and performance.

Modular design for high cooling capacity

Available in 60, 90, 130, and 180 kBTU/h models, the BlueCool V-Pro Series can combine up to six units, delivering up to 1,080,000 BTU/h of cooling.

Autonomous control system

Each unit operates independently with its own control electronics and color touchscreen interface, simplifying system setup and operation.

Durable titanium condensers

Built with corrosion-resistant titanium condensers, the BlueCool V-Pro Series is engineered for long-lasting performance, even in demanding marine conditions.

Flexible system configuration

Supports a range of accessories, including stainless steel racks, ABS manifolds, and control boxes, allowing for customized setups based on vessel size and cooling needs.

Product details

Product specifications



BlueCool V-PRO 60M

  • Part number: 2510228
  • Cooling capacity (BTU/h): 15,000 – 60,000
  • Cooling capacity (kW): 4.4 – 17.6
  • Heating via Reverse Cycle: Integrated
  • Voltage (V): 400 V (50 Hz) – 460 V (60 Hz) 3 phase +N
  • Frequency (Hz): 50 / 60
  • Current draw running (A): 1.5 – 7.5 (max. 10)
  • Max. current draw in Eco 1 Mode (A): 1.5 – 5.5 (max. 6.3)
  • Max. current draw in Eco 2 Mode (A): 1.5 – 3.9 (max. 4.8)
  • Max. current draw in Eco 3 Mode (A): 1.5 – 2.9 (max. 3.8)
  • Sea water connection (inch / mm): G 1-1/4” (IG 32mm)
  • Chilled water connection (inch / mm): G 1-1/4” (IG 32mm)
  • Dimensions (L x D x H) (inch / mm): 24.8 x 16.1 x 25.6 / 630 x 410 x 650
  • Weight (lb / kg): 196.2 / 89

BlueCool V-PRO 90M

  • Part number: 2510229
  • Cooling capacity (BTU/h): 22,500 – 90,000
  • Cooling capacity (kW): 6.6 – 26.4
  • Heating via Reverse Cycle: Integrated
  • Voltage (V): 400 V (50 Hz) – 460 V (60 Hz) 3 phase +N
  • Frequency (Hz): 50 / 60
  • Current draw running (A): 2.9 – 15.5 (max. 18.5)
  • Max. current draw in Eco 1 Mode (A): 2.9 – 10.7 (max. 11.3)
  • Max. current draw in Eco 2 Mode (A): 2.9 – 7.6 (max. 8.3)
  • Max. current draw in Eco 3 Mode (A): 2.9 – 5.7 (max. 6.5)
  • Sea water connection (inch / mm): G 1-1/4” (IG 32mm)
  • Chilled water connection (inch / mm): G 1-1/4” (IG 32mm)
  • Dimensions (L x D x H) (inch / mm): 32.7 x 16.1 x 25.6 / 830 x 410 x 650
  • Weight (lb / kg): 213.8 / 97

BlueCool V-PRO 130M

  • Part number: 2510230
  • Cooling capacity (BTU/h): 19,500 – 130,000
  • Cooling capacity (kW): 5.7 – 38.1
  • Heating via Reverse Cycle: Integrated
  • Voltage (V): 400 V (50 Hz) – 460 V (60 Hz) 3 phase +N
  • Frequency (Hz): 50 / 60
  • Current draw running (A): 4.0 – 20 (max. 23)
  • Max. current draw in Eco 1 Mode (A): 4.0 – 13.6 (max. 14.9)
  • Max. current draw in Eco 2 Mode (A): 4.0 – 9.1 (max. 10.4)
  • Max. current draw in Eco 3 Mode (A): 4.0 – 7.1 (max. 8.4)
  • Sea water connection (inch / mm): G 1-1/4” (IG 32mm)
  • Chilled water connection (inch / mm): G 1-1/4” (IG 32mm)
  • Dimensions (L x D x H) (inch / mm): 32.7 x 16.1 x 25.6 / 830 x 410 x 650
  • Weight (lb / kg): 264.5 / 120

BlueCool V-PRO 180M

  • Part number: 2510231
  • Cooling capacity (BTU/h): 27,000 – 180,000
  • Cooling capacity (kW): 7.9 – 52.8
  • Heating via Reverse Cycle: Integrated
  • Voltage (V): 400V (50Hz) – 460V (60Hz) 3 phase +N
  • Frequency (Hz): 50 / 60
  • Current draw running (A): 4.6 – 23 (max. 25)
  • Max. current draw in Eco 1 Mode (A): 4.6 – 16.8 (max. 18)
  • Max. current draw in Eco 2 Mode (A): 4.6 – 11.6 (max. 12.5)
  • Max. current draw in Eco 3 Mode (A): 4.6 – 9 (max. 10)
  • Sea water connection (inch / mm): G 1-1/4” (IG 32mm)
  • Chilled water connection (inch / mm): G 1-1/4” (IG 32mm)
  • Dimensions (L x D x H) (inch / mm): 32.7 x 16.1 x 25.6 / 830 x 410 x 650
  • Weight (lb / kg): 299.8 / 136

Downloads

BlueCool V-PRO Series - Datasheet

Size
427 KB
Format
application/pdf
Download
