BlueCool VX-Series

Jump to section

Variable speed chiller units designed for seamless integration, offering eco-friendly and energy-efficient cooling

The Webasto BlueCool VX-Series is the ultimate air-conditioning solution for boats and yachts with multiple cabins. Featuring variable speed control and modular units ranging from 36 to 72 kBTU/h, the VX-Series provides powerful, customizable cooling for vessels of all sizes. The system is designed for efficiency, using eco-friendly R32 refrigerant and reducing power consumption by 20 %. With a compact design and corrosion-resistant titanium condenser, the BlueCool VX-Series is ideal for space-saving installations while maintaining quiet, high-performance operation.

BlueCool VX-Series

BlueCool VX-Series and BlueCool MyTouch

BlueCool VX-Series
BlueCool VX-Series rack
BlueCool VX-Series and MyTouch

Discover the advantages of the VX-Series

The Webasto BlueCool VX-Series offers exceptional cooling performance for medium-sized boats to superyachts, providing flexibility with its modular design. Units can be combined to achieve cooling capacities up to 216 kBTU/h, making the VX-Series suitable for a wide range of vessels. With its variable speed compressors, the system adjusts to ambient conditions for optimal efficiency, achieving an Energy Efficiency Ratio (EER) of up to 5.6. The BlueCool VX-Series uses R32 refrigerant, which reduces environmental impact, and features corrosion-resistant components for long-lasting performance. The system is easy to control and monitor via the MyTouch display, which supports multiple languages and allows centralized control of the entire setup.

Modular design for custom cooling

Combine units ranging from 36 to 72 kBTU/h to create a system with up to 216 kBTU/h, perfect for boats and yachts of all sizes.

Eco-friendly and energy efficient

Uses R32 refrigerant and reduces power consumption by 20 %, achieving an Energy Efficiency Ratio (EER) of up to 5.6 for cost-effective operation.

Space-saving and quiet operation

Compact design saves up to 55 % more space compared to other systems, while vibration-damping components ensure quieter onboard comfort.

Advanced control features

The MyTouch display offers multilingual support, water flow monitoring, and centralized control via the VX-system bus, making it easy to manage the entire system.

Product details

Product specifications

BlueCool VX 36M, VX 48M, VX 60M, VX 72M, VX 72M 3~, VX 120M

Cooling capacity [BTU/h] [kW]: 3,400 – 120,000 (1 – 35.2 kW)

VX 36M: 3,400 – 36,000 (1 – 10.5 kW)
VX 48M: 6,900 – 48,000 (2 – 14 kW)
VX 60M: 5,900 – 60,000 (1.7 – 17.6 kW)
VX 72M: 7,100 – 72,000 (2.1 – 21 kW)
VX 72M 3~: 7,100 – 72,000 (2.1 – 21 kW)
VX 120M: 10,000 – 120,000 (2.9 – 35.2 kW)

Heating capacity [BTU/h] [kW] (Reverse Cycle Mode): 44,000 – 121,000 (12.9 – 35.5 kW)

VX 36M: 44,000 (12.9 kW)
VX 48M: 58,000 (17 kW)
VX 60M: 63,000 (18.5 kW)
VX 72M: 78,000 (23 kW)
VX 72M 3~: 78,500 (23 kW)
VX 120M: 121,000 (35.5 kW)

Dimensions (H/W/L) [mm] [Inch]:

VX 36M: 533 x 352 x 378 (21 x 13.9 x 14.9 in)
VX 48M: 534 x 398 x 429 (21 x 15.7 x 16.9 in)
VX 60M: 593 x 399 x 479 (23.3 x 15.7 x 18.9 in)
VX 72M: 683 x 398 x 546 (26.9 x 15.7 x 21.5 in)
VX 72M 3~: 698 x 401 x 546 (27.5 x 15.8 x 21.5 in)
VX 120M: 766 x 401 x 638 (30.2 x 15.8 x 25.1 in)

Voltage / Phase: 230 V 1-Phase, 208 V 3-Phase, 230 V 1-Phase
Frequency [Hz]: 50/60 Hz
Current draw running [A]: 3 – 36 (varies by model)
Current draw ECO Mode (1 – 2 – 3) [A]: 4.3 – 27 (varies by model)
Current draw start [A]: 3 – 4 (varies by model)

Chilled water connection [mm] [Inch]:

VX 36M: IG 25 - BSPP Female 1"
VX 120M: IG 32 - BSPP Female 1 1/4"

Sea water connection [l/min]:

VX 36M: IG 25 - BSPP Female 1"
VX 120M: IG 32 - BSPP Female 1 1/4"

Minimum flow rate (SW / CW) [l/min]: 33 – 100 (varies by model)
Weight [kg]: 49 – 130 (varies by model)
Energy efficiency (EER): Up to 5.6
Refrigerant / GWP: R32 / 675, R410a / 2088
