FCF
Classic
Efficient, quiet marine cooling with FCF Classic self-contained units
The Webasto FCF Classic self-contained air conditioning units deliver efficient and quiet cooling for boats with up to three cabins. Available in 12,000 and 16,000 BTU/h models, these units feature a balanced system that minimizes noise and vibration. Each unit includes a robust blower, a corrosion-free stainless steel condensation tray, and a digital control panel, ensuring reliable performance in marine environments. The FCF Classic is equipped with reverse cycle heat for year-round comfort and comes with a remote control for added convenience.
Discover the advantages of the FCF Classic
The Webasto FCF Classic is designed to provide exceptional comfort in marine environments, offering reliable cooling and heating for up to three cabins. With models available in 12,000 and 16,000 BTU/h, these self-contained units are compact, quiet, and easy to install. The FCF Classic features a carefully balanced compressor system to reduce noise and vibration, ensuring a peaceful onboard environment. The system includes a high-velocity, 360° rotatable blower that can handle multiple vents, along with a corrosion-resistant stainless steel condensation tray for long-lasting durability. Standard reverse cycle heat ensures comfort in any season, and the included remote control allows you to manage your system from anywhere on the vessel.
Product details
Product specifications
FCF Classic 12,000
Rated voltage: 115V
Part number: FCF0012000GS
Cooling capacity: 12,000 BTU/h
Rated frequency: 60Hz
Average load: 8.5 A
Min. supply air: 50 in² (323 cm²)
Min. return air: 100 in² (645 cm²)
Net weight: 68 lbs. (31 kg)
Blower output: 410 cfm (696 m³/h)
Ducting collar (Diameter): 5 in (127 mm)
Seawater inlet / outlet (Diameter): 0.750 in (19 mm)
Drain pan outlet (Diameter): 0.625 in (15.9 mm)
FCF Classic 16,000
Rated voltage: 230V
Part number: FCF0012023G
Cooling capacity: 16,000 BTU/h
Rated frequency: 50 / 60Hz
Average load: 4.5 A
Min. supply air: 60 in² (387 cm²)
Min. return air: 140 in² (903 cm²)
Net weight: 76 lbs (33 kg)
Blower output: 505 cfm (858 m³/h)
Ducting collar (Diameter): 5 in (127 mm)
Seawater inlet / outlet (Diameter): 0.750 in (19 mm)
Drain pan outlet (Diameter): 0.625 in (15.9 mm)
