Air Top Evo 40/55

Experience ultimate comfort with the Air Top Evo 40/55 heater

The Air Top Evo 40/55 is a powerful air heater designed for maximum comfort in any environment. With a heating capacity of up to 19,000 BTU/h, it delivers consistent warmth quickly and efficiently. Its compact design and quiet operation make it perfect for use in various applications, ensuring you stay comfortable without unnecessary noise or energy waste.

Product picture of Air Top Evo 40/55 heater

Discover the advantages of the Air Top Evo 40/55

The Air Top Evo 40/55 combines cutting-edge technology with exceptional efficiency, making it the ideal solution for reliable heating. With its powerful performance and low fuel consumption, you can enjoy warm, cozy spaces without breaking the bank. This heater is designed for easy installation and maintenance, ensuring you spend less time worrying about your heating system and more time enjoying the comfort it provides. The Air Top Evo 40/55 also features smart diagnostics, providing you with valuable insights for optimal operation.

Powerful heating performance

Delivers up to 19,000 BTU/h, ensuring rapid warmth in any environment. Ideal for keeping your space cozy and comfortable, no matter the weather outside.

Compact, space-saving design

The sleek, compact design allows for flexible installation in tight spaces. Maximize your usable area without sacrificing heating performance.

Low fuel consumption

Engineered for efficiency, this heater consumes minimal fuel while providing maximum output. Enjoy significant cost savings while staying warm and comfortable.

User-friendly diagnostics

Equipped with smart diagnostics that monitor performance and efficiency. Receive valuable insights to optimize usage and ensure reliable operation.

Product details

Product specifications



Fuels:
Diesel, Biodiesel, Gasoline (for both models)



Nominal voltage:
12 V, 24 V (for both models)



Heating capacity, control range / boost:
5,100 – 12,000 / 13,650 BTU/h (1.5 – 3.5 / 4.0 kW) (Air Top Evo 40, Diesel)
5,800 – 12,000 / 13,650 BTU/h (1.7 – 3.5 / 4.0 kW) (Air Top Evo 40, Gasoline)
5,100 – 17,000 / 18,800 BTU/h (1.5 – 5.0 / 5.5 kW) (Air Top Evo 55, Diesel)
5,800 – 17,000 / 18,800 BTU/h (1.7 – 5.0 / 5.5 kW) (Air Top Evo 55, Gasoline)



Fuel consumption, control range / boost:
0.05 – 0.11 / 0.13 gal/h (0.18 – 0.43 / 0.49 l/h) (Air Top Evo 40, Diesel)
0.07 – 0.14 / 0.15 gal/h (0.25 – 0.51 / 0.58 l/h) (Air Top Evo 40, Gasoline)
0.05 – 0.16 / 0.18 gal/h (0.18 – 0.61 / 0.67 l/h) (Air Top Evo 55, Diesel)
0.07 – 0.19 / 0.21 gal/h (0.25 – 0.73 / 0.80 l/h) (Air Top Evo 55, Gasoline)



Rated power consumption, control range / boost @ 12 V:
1.25 – 3.3 / 4.58 Amps (15 – 40 / 55 W) (Air Top Evo 40)
1.25 – 7.9 / 10.8 Amps (15 – 95 / 130 W) (Air Top Evo 55)



Operating temperature range:
–40 to +104 °F (–40 to +40 °C) (for both models)



Heating air volume flow against 0.5 mbar, control range / boost:
77.7 / 82.4 cfm (132 / 140 m³/h) (Air Top Evo 40)
117 / 129.5 cfm (200 / 220 m³/h) (Air Top Evo 55)



Dimensions (L x W x H):
16.7 x 5.8 x 6.4 in (423 x 148 x 162 mm) (for both models)



Weight:
13 lbs (5.9 kg) (for both models)



Automatic altitude compensation:
18,044 ft (5,500 m) (Air Top Evo 40)
7,218 ft (2,200 m) (Air Top Evo 55)



ECE approval number ECE R122 (heating):
E1 00 0385 (Air Top Evo 40)
E1 00 0386 (Air Top Evo 55)



ECE approval number ECE R10 (EMC):
E1 04 5529 (for both models)
