BlueCool C-Series
Ultra-compact chiller
These standardized Webasto chiller systems are suitable for small and medium-sized boats with several cabins. Whenever three or more independent areas of a yacht need to be air-conditioned, this central cooling system is the right choice.
The extremely compact units in the BlueCool C-Series are usually located in the engine room and supply all cabins with pleasantly cool air via a chilled water circuit and air outlets. They cool with an output of 16,000 to 40,000 BTU/h (4.7 to 11.7 kW) and can also heat via a reverse function. Vibration dampers and soft-start accessories are optionally available.
Benefits of BlueCool C-Series
Product details
Product specifications
Model: C16 M
- Cooling capacity: 16,000 BTU/h / 4.7 kW
- Number of compressors: 1
- Supply voltage: 230 V
- Current draw: 4.4 – 6.0 A
- Net weight: 66 lbs / 30 kg
- Dimensions (L x W x H): 15.2 x 11.4 x 13.8 in (385 x 290 x 350 mm)
Model: C20 M
- Cooling capacity: 20,000 BTU/h / 5.9 kW
- Number of compressors: 1
- Supply voltage: 230 V
- Current draw: 6.9 – 8.0 A
- Net weight: 66 lbs / 30 kg
- Dimensions (L x W x H): 17.3 x 12.6 x 14.4 in (440 x 320 x 365 mm)
Model: C27 M
- Cooling capacity: 27,000 BTU/h / 7.9 kW
- Number of compressors: 1
- Supply voltage: 230 V
- Current draw: 8.6 – 9.2 A
- Net weight: 88 lbs / 40 kg
- Dimensions (L x W x H): 17.3 x 13.4 x 15.7 in (440 x 340 x 400 mm)
Model: C32 T
- Cooling capacity: 32,000 BTU/h / 9.4 kW
- Number of compressors: 2
- Supply voltage: 230 V
- Current draw: 8.8 – 12.0 A
- Net weight: 169 lbs / 77 kg
- Dimensions (L x W x H): 20.9 x 15.7 x 19.3 in (530 x 400 x 490 mm)
Model: C40 T
- Cooling capacity: 40,000 BTU/h / 11.7 kW
- Number of compressors: 2
- Supply voltage: 230 V
- Current draw: 13.8 – 16.0 A
- Net weight: 176 lbs / 80 kg
- Dimensions (L x W x H): 20.9 x 15.7 x 19.3 in (530 x 400 x 490 mm)
Model: C55 T
- Cooling capacity: 55,000 BTU/h / 16.1 kW
- Number of compressors: 2
- Supply voltage: 230 V
- Current draw: 17.2 – 18.4 A
- Net weight: 198 lbs / 90 kg
- Dimensions (L x W x H): 20.9 x 15.7 x 21.7 in (530 x 400 x 550 mm)
Model: C81 R
- Cooling capacity: 81,000 BTU/h / 23.7 kW
- Number of compressors: 3
- Supply voltage: 230 V
- Current draw: 25.8 – 27.6 A
- Net weight: 308 lbs / 140 kg
- Dimensions (L x W x H): 29.5 x 16.5 x 21.7 in (750 x 420 x 550 mm)
Model: C108 Q
- Cooling capacity: 108,000 BTU/h / 31.7 kW
- Number of compressors: 4
- Supply voltage: 230 V
- Current draw: 34.4 – 36.8 A
- Net weight: 385 lbs / 175 kg
| Model overview | Thermo Top Eveo 4 | Thermo Top Evo 5 | Thermo Top Evo 5+* | |||
|---|---|---|---|---|---|---|
| Diesel | Gasoline | Diesel | Gasoline | Diesel | Gasoline | |
| ECE approval number ECE R12 (heating) | E1 00 0258 | E1 00 0258 | E1 00 0258 | |||
ECE approval number ECE R10 | E1 04 5627 | E1 04 5627 | E1 04 5627 | |||
| Heating capacity, part load/ full load (kW) | 2.5/4.0 | 2.8/4.0 | 2.5/5.0 | 2.8/5.0 | 2.5/5.0 | 2.8/5.0 |
| Fuel consumption, part load / full load (l/h) +/- 10% | 0.31/0.49 | 0.39/0.56 | 0.31/0.62 | 0.39/0.70 | 0.31/0.62 | 0.39/0.70 |
| Nominal voltage | 12 | 12 | 12 | |||
| Rated power consumion without coolant pump, part load/ful l load (W) without vehicle’s fan, +/- 10% | 12/21 | 15/21 | 12/33 | 15/33 | 12/33 | 15/33 |
| Fuels | Diesel DIN EN 590,Paraffinic fuel (HVO / GTL)DIN EN 15940 | E0-E10 EN 228, E85 DIN 51625 | Diesel DIN EN 590,Paraffinic fuel (HVO / GTL)DIN EN 15940 | E0-E10 EN 228, E85 DIN 51625 | Diesel DIN EN 590,Paraffinic fuel (HVO / GTL)DIN EN 15940 | E0-E10 EN 228, E85 DIN 51625 |
| Operating temperature range (°C) | -40 to +60 | |||||
| Dimensions L x W x H (mm) | 218 x 91 x 147 | 218 x 91 x 147 | 218 x 91 x 147 | |||
| Weight (kg) | 2.1 | 2.1 | 2.1 | |||
| Coolant pump U4847 Econ | - | |||||
| Volume flow against 0.14 bar (l/h) | 500 | |||||
| Dimensions L x W x H (mm) | 109x49x79 | |||||
| Weight (kg) | 0.3 | |||||
* More details can be found here
